Leister NOVOLAS Basic AT - Analogue Inputs (X16); Analogue Outputs (X17)

NOVOLAS Basic AT Version 2.1
09/2010
24 Interfaces
4.3.4 Analogue Inputs (X16)
General specification:
• Voltage range 0 to 10 Volt
• Impedance app. 50 kOhm
• Maximum voltage 35 Volt
• Attention! Common reference potential with analogue outputs and
serial ports
Terminal Description Potential
X16.1 Signal Common GND
X16.2 Modulation signal Laser Unit#B (#D) (optional)
X16.3 Modulation signal Laser Unit#A (#C) (optional)
X16.4 Current preset laser unit #B (#D),
(usually 1V per 10A)
X16.5 Current preset laser unit #A (#C),
(usually 1V per 10A.)
4.3.5 Analogue Outputs (X17)
General specification:
• Voltage range 0 to 10 Volt
• Impedance app. 10 kOhm
• Max. Output current 1mA
• Attention! Common reference potential with analogue inputs and
serial ports
Terminal
Beschreibung
Potential
X17.1 Signal Common GND
X17.2 Pyrometer signal Laser Unit#B (#D) (optional)
X17.3 Pyrometer signal Laser Unit#A (#C) (optional)
X17.4 Current feedback Laser Unit #B (#D)
(typisch 1V pro 10A)
X17.5 Current feedback Laser Unit #A (#C)
(typisch 1V pro 10A)
