Version 2.1
09/2010
NOVOLAS Basic AT
Technical Data 61
10.4 Laser power supply and laser module
Up to 4 laser modules and power supplies can be installed. Maximum ratings for the
individual modules are given below.
Laser safety class (system) Laser Class 4 according to EN60825-1
High power diode laser Laser Class 4 according to EN60825-1
Aiming laser Laser Class 2M according to EN60825-1
High power diode laser
wavelength
800-1000 nm
Aiming laser wavelength 620-680 nm
High power diode laser
power
Fiber coupled lasers: max. 400 W cw at aperture of
each laser module
Aiming laser power max. 5 mW cw at aperture of each laser module
Type of operation controlled current operation
Min. bending radius of fiber Min.200 mm: for SMA fiber
Min. 250 mm for HiYAG fiber
10.5 Liquid Cooling System
Cooling medium de-ionized water
(conductivity: 5-10 µS, filtered < 20 µm)
Capacity approx. 3.5 liter (total incl. pump, filter and tubes)
Filter unit 20 µm
Water tube use only the tubes supplied by Leister!
10.6 Conductor cross-sections
Wires mm2 Remark
0.25 Analog and digital signals such as
EMERGENCY STOP, Reset etc.
2.5 230 VAC (mains cable before fuse)
1.6 230 VAC (mains cable behind fuses)
