Leister NOVOLAS Basic AT - Typical Wiring of a Basic AT with an External Laser Unit (i.e. Linebeam)

NOVOLAS Basic AT Version 2.1
09/2010
38 Installation
5.5.2 Typical wiring of a Basic AT with an external laser unit (I.e. Linebeam)
Laser unit not ready
Operation Mode Setting
Register Value
0 2
1 0
2 1
Input
X90.1
X90.2
X90.3
X90.4
X90.5
X90.6
X91.1
X91.4
X91.2
X91.3
X14.1
X14.8
X14.9
X14.10
X16.1
X16.5
Output
X90.7
X90.8
X90.9
X15.1
X15.7
X15.8
X15.9
X15.10
X80.-
X80.+
X81
EI
Start, Reset
close min. 100ms
to start system
Emergency
Stop
open to stop
operation
Interlock, close
for lasing
Ext. 24V
Power
supply
Laser on/off
close to switch
on laser
Internal connection
U
Set laser current
1V=15A
+24V
0V
AT Electrical
Interface
Warning
laser system
powered,
redundant
Laser unit ready
Laser on
Laser
Head
X29
X29
X30
X25
Figure 15: Typical wiring of a Basic AT with an external laser unit
