LELY LOTUS 600 - 1.1.4 Gauge Wheel Set

1.1.4 Gauge Wheel Set
A gauge wheel is installed on the headstock to improve the following of
ground contours. This may be necessary on hilly terrain to optimize the
tedding result. A chain replaces the top link and the gauge wheel takes over
the leveling function from the top link.
1. Gauge wheel set
Figure 6. Gauge Wheel Set
Introduction 1-5
4.1046.8504.0 A
