4.2 Adjust the height of the rotor wheels
Procedure
1.
Move the Lotus to the headland position (see "Move the Lotus from
the working position to the headland position" on page 3‑
15).
2. Switch off the tractor engine.
3. Make sure the rotors can not move downwards.
4. Remove the pin from the wheel assembly.
5. Adjust the wheel assembly to the required height (Figure 24, page 4‑
3) position:
• Position A is used on the outer rotors during transport to create a
smaller transport width.
• Position A is used on the two inner rotors when disconnecting the
Lotus in transport position.
• Position B is recommended when working with light and short
crops or windy conditions.
• Position B or C are recommended when making or moving
windrows.
• Position C and D are the intermediate positions defined by the
operator.
• Position E is recommended when working with heavy and long
crops.
6. Install the pin in the required hole of the wheel assembly.
7. Secure the pin with the locking pin.
4-2 Operation adjustments
4.1046.8504.0 A
