LELY LOTUS 600 - 7. SPECIFICATIONS

7. SPECIFICATIONS
The specifications of the Lotus are defined in the following table:
Lotus 600 Stabilo 600 Stabilo Combi
Working width 6.00 m (19.68 ft) 6.00 m (19.68 ft)
Transport width 3.00 m (9.84 ft) 3.00 m (9.84 ft)
Transport height 2.80 m (9.18 ft) 2.80 m (9.18 ft)
Transport length 2.00 m (6.56 ft) 2.00 m (6.56 ft)
Approximate tedding angle 10º - 17º 10º - 17º
Number of rotors 4 4
Number of tines per rotor 8 double tines 8 double tines
Linkage categorie ll categorie ll
Hydraulic connections 1 double-acting valve
with floating position
Max. oil pressure 21.0
MPa (210 bar)
1 double-acting valve
with floating position
Max. oil pressure 21.0
MPa (210 bar)
PTO speed 450 - 500 rpm, max.
540 rpm
450 - 500 rpm, max.
540 rpm
Security K33B slip clutch K33B slip clutch
Operating speed Max. 15 km/h Max. 15 km/h
Transport speed Max. 25 km/h Max. 25 km/h
Rotor tyre size 16/6.5-8 6 ply 16/6.5-8 6 ply
Power requirement 44 kW (60 HP) 44 kW (60 HP)
Approximate weight 830 kg (1830 lb) 930 kg (2050 lb)
All specifications may be changed without prior notice.
Note:
Specifications 7-1
4.1046.8504.0 A
