1.1.5 Spare rotor wheel
The spare wheel support can be installed on the Lotus to carry a spare
wheel. So that a flat tyre can be changed quickly in the field.
1. Spare rotor wheel
Figure 7. Spare rotor wheel
1-6 Introduction
4.1046.8504.0 A
