9.2.6 Electrics
► Perform visual inspection of the connector plugs and cables.
n Watch for bent or broken contact pins in the plugs.
n Watch for exposed places in cables.
ð
Repair damaged connector plugs or cables immediately or
have them replaced.
9.2.7 Checking the soil cultivation tools
1.
Visual inspection
n Damage
n Wear
2. Immediately replace damaged concave discs.
3. Replace worn concave discs that measure less than 460 mm in
diameter.
Ä
Chapter 9.4.1 ‘Replacing concave discs’ on page 73
► Visual inspection
n Damage
n Wear
Replace damaged or worn soil cultivation implements.
Ä
Chapter 6.1 ‘Changing the setup state’ on page 41
Ä
Chapter 9.4 ‘Work instructions’ on page 73
Checking connector plugs and cables
Check the concave discs
Checking soil cultivation implements
Maintenance and repair work
en-GB | Item no. 17516276 | BA 01/2023-09 69
