12 Technical data
12.1 About the technical data
Machine variants may have varying technical data.
Dierent machine variants are potentially distinguished in the technical
data by means of abbreviated product designations, e.g. type designa‐
tion on the type plate:
Ä Appendix A ‘Type plate variants’ on page 88
12.2 Dimensions
Karat 10 300 350 400
Transport length, max. [mm] 5000 5000 5000
Transport length, min. [mm] 4000 4000 4000
Transport width, max. [mm]* 3000 3500 4000
Working width, max. [mm] 2994 3440 3982
To determine the actual dimensions: Measure the machine.
* Transport width: Observe applicable national regulations.
12.3 Machine weights
Karat 10 300 350 400
Total weight, max. [kg]* 1600 1800 2000
* For determining the actual weights: Weigh the machine.
12.4 Permissible mass and loads
The maximum permissible total mass, drawbar load and axle load of
the machine are listed on its type plate.
If the load capacities of the wheels are lower than the permissible
axle loads, the permissible axle load is limited to the permissible load
capacity of the wheels.
INFORMATION
Observe the national regulations / laws and, if necessary,
approval documentation.
Machine variants
Technical data
en-GB | Item no. 17516276 | BA 01/2023-09 79
