Checklist for preparing the tractor
Assembly group Requirement Check
Tyres
Ä Chapter 12.10 ‘Tyres
and wheels’ on page 81
The air pressure of the tractor tyres corresponds to the instructions of
the tractor manufacturer.
c
The air pressure is the same in all the tyres of one axle.
c
Under dicult conditions:
Additional wheel weights are used or the tyres are lled evenly with
water.
c
Lifting rods
The length of the lifting rods corresponds to the instructions of the
tractor manufacturer.
c
The lifting rods of the tractor are adjusted to the same length.
c
The lifting rods are set rigidly. For this purpose, the slots are locked.
c
Check chains and stabil‐
isers
Working in the eld:
For sucient lateral movement, the lower links move freely.
c
Road travel:
To ensure the machine is positioned centrally behind the tractor, the
lower links are secured in place (no lateral movement).
4.2 Attaching the machine
4.2.1 Practical knowledge - Eects of the mounting position
INFORMATION
The following description of the cross shaft position also
applies accordingly to the position of the lower link pins.
The top link mounting position can be changed at the tractor and at
the machine.
The dierent combinations of the top link and the lower link mounting
positions have an eect on the behaviour of the machine during opera‐
tion.
INFORMATION
The traction line
3
between the machine and the tractor
starts at the point where the extended lines of the top
link and the lower link intersect.
