Screws and nuts made of stainless steel
Diameter [Nm*]
A2-70 A4-80
M5 4.5 6.0
M6 8.0 11.5
M8 19.0 25.5
M10 38.0 51.0
M12 65.0 87.0
M14 105 140
M16 160 215
M20 315 420
M24 545 735
* µ
tot
= 0.14
B.3 Tightening torques for wheel bolts and wheel nuts
Implements Diameter / thread [Nm]
Every M14 x 1,5 125
Every M18 x 1,5 290
Every M22 x 1,5 510
Exceptions:
Implements Diameter / thread [Nm]
Diamant 12 M18x 1,5 380
Karat 9 KA to 8/2016 M12 x 1,5 380
Karat 12 KA to 8/2016 M22 x 1,5 380
Gigant 10 M12 x 1,5 380
Tightening torques screws
