LEMKEN Opal 080 E - Attaching the Implement; Specific Safety Information; General

Attaching the implement
35
8 ATTACHING THE IMPLEMENT
8.1 Specific safety information
WARNING
Risk of injury from the parked implement
 Never enter the danger zone between the tractor and imple-
ment.
 Read and observe the "Safety measures and precautions" sec-
tion and the special safety instructions "Risk of injury from the
parked implement".
The implement is not a play area.
Climbing on the parked implement may cause serious injuries,
e.g. as a result of slipping or tripping.
Do not climb on the parked implement.
8.2 General
Attach the plough parked in working positi-
on to the tractor as follows:
 Switch the tractor's hydraulic system to
position control.
 Connect the lower link to the cross shaft
(1).
 Secure the lower link.
 Use the tractor's hydraulic system to lift
the implement until the stand is suffi-
ciently raised from the ground.
 Remove the connector pin (2).
 Remove the stand (3).
1
3
2
