46
11.6.4 Sword Coulter
Fit the sword coulter (1) in front of the
landslide (2) of the plough body.
11.7 Shearing protection
Each plough body is equipped with shea-
ring protection (1) to safeguard against
overloading.
If an excess load is applied to a plough
body, the shear bolt (1) shears off. The
plough body swivels to the rear.
Risk of being crushed and injured due to moving compo-
nents
When a shear bolt shears off, the plough body is movable. There
is a risk of being crushed and injured in the turning range of the
plough body.
When repairing the plough body:
Always stand behind the plough body in the direction of travel
when carrying out work.
Pay particular attention during repair work.
