Maintenance and repairs
55
13.4.2 Bolts and nuts made of steel
Diameter
Strength category
8.8 [Nm*]
10.9 [Nm*]
12.9 [Nm*]
M 6
9,7
13,6
16,3
M 8
23,4
32,9
39,6
M 10
46,2
64,8
77,8
M 12
80,0
113
135
M 14
127
178
213
M 16
197
276
333
M 20
382
538
648
M 24
659
926
1112
M 30
1314
1850
2217
*μ
g
= 0,12
13.5 Check the connections to the tractor
13.5.1 Hydraulic connections
WARNING
Risk of accidents due to escaping hydraulic fluid
Hydraulic fluid which is ejected under high pressure (hydraulic oil)
can penetrate the skin and cause serious injuries. In the event of
injuries, consult a doctor immediately.
 Due to the risk of injury, always use suitable tools when looking
for leaks.
 Always wear appropriate protective clothing.
 Carry out a visual inspection of the hydraulic couplings.
 Look for leaking hydraulic oil at the hydraulic couplings.
 Connect the hydraulic lines to the tractor.
 Check that the hoses are leak-free when under pressure.
Faulty or leaking couplings must be repaired or replaced immediately by a specia-
list workshop.
