LEMKEN Opal 080 E - Working Width for each Body; Tail Pieces

Operation
45
11.6.2 Working width for each body
The working width for each body is chan-
ged using wedges (1) that are screwed
between the leg (2) and the frog (3). Three
working widths are possible for each body.
 Narrow side of the wedge (1) points for-
wards
=> less working width for each body
 Without wedges
=> medium working width for each body
 Wide side of the wedge (1) points for-
wards
=> more working width for each body
11.6.3 Tail Pieces
The tail pieces (2) being positioned at the
end of the mouldboards (1) help to turn the
furrow slice.
 Adjust all tail pieces uniformly.
Set too deeply, they can cause soil to fall
back into the furrow.
1
2
3
2
3
3
2
1
