Troubleshooting: Assist
Flybridge Keypads
Flybridge keypads do not allow
configurations or performance adjustments,
these must be done at the main keypad
station. All other functions and controls are
the same as the main keypad station.
Troubleshooting
Troubleshooting Pro Control Assist
Symptom Status Cause Resolution
Keypad does not
respond to inputs
Condition:
keypad NOT lit
Keypad not powered
by L2K bus, as
required
Secure all NMEA® and
L2K cabling connections:
ensure Purple wire is
connected on 10 pin or
SmartCraft® is connected
to Mercury Junction Box
on SmartCraft® equipped
vessels.
Contact Navico Group™
or Mercury service
Wake wire not
receiving power
Condition:
keypad lit
Actuators not powered
over L2K bus
Actuators not receiving
commands over L2K
CAN
Holeshot mode is
not operational when
throttle moved from low
speed to full open
The FAV tab positions
have not been set
Set and store a FAV1
position
GPS not installed Approved GPS to the
N2K CAN
Enter Commissioning
mode on keypad and
confirm GPS connection.
Set GPS to global, if
applicable.
Set and Save FAV tab
position greater than 0.
GPS not set to global
in MFD
keypad back light
not visible
Back light setting
on ‘night’ setting
during bright
sun light.
Excessively bright
sunlight makes the
back light diicult to
see
Adjust DAY/NIGHT mode
Adjust brightness
Press of FAV button
causes FAV LED to
double flash
FAV position not saved Save FAV trim tab
position
Port or Starboard
actuator does not
respond to command
Keypad and
one actuator
operating
properly
Faulty actuator Secure all NMEA®
and L2K cabling
connections:check
power to non-functioning
actuator
Contact Navico Group™
or Mercury service
Converting to Tab Centric
The system can be converted from ‘boat centric’ to
‘tab centric’, this reverts the buttons and dial control to
the opposite trim tab. The system is automatically set
to ‘boat centric’.
Example: the port lower UP button controls the
starboard tab in ‘boat centric’.
In Tab Centric mode the port UP button will control the
port tab. We do not recommend setting up the vessel
in this configuration.
