•“1020Largebottomcover”onpage62
•“1030Smallbottomcover”onpage63
•“1040Opticaldriveorblankbezel”onpage64
•“1070PCIExpressMiniCardforwirelessLANandbracket”onpage68
•“1110Keyboard”onpage73
•“1120Keyboardbezel”onpage76
•“1190RJ45subcard”onpage87
•“1210LCDunit”onpage90
•“2010LCDbezelassembly”onpage96
RemovalstepsoftheLCDpanelandhinges
1
1
1
1
StepScrew(quantity)Color
Torque
1
M2.5×4mm,wafer-head,nylon-coated(4)
Black0.294Nm
(3kgf-cm)
2
2
98HardwareMaintenanceManual
