Lenovo ThinkPad Edge E545 Service Manual

Formodelswithdiscretethermalpipes
a
a
b
Formodelswithintegratedthermalpipes
a
b
•Donottouchthethermalgrease.
•Donotpress,touch,orrotatethefanimpeller.
•Donottouchthefaninlethole.
•Donottwistorpullthecableofthethermalfanassembly.
•Donotapplypressureonthetopandbottomcoversofthethermalfanassembly.
•Donotpresstheheatpipe.Holdbothsidesoftheheatpipeifyouneedtotakethethermalfanassembly.
•Donotshakeordropthethermalfanassembly.
•Ensurethatthefanconnectorisattachedrmly.
•Replacethethermalfanassemblyifyouobservethefollowing:
–Thecoverofthethermalfanassemblyisdeformedordamaged.
–Thereisabnormalnoiseduringrotation.
1110Keyboard
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage62
Chapter9.RemovingorreplacingaFRU73

Lenovo ThinkPad Edge E545 Specifications

General

OS	windows 7 professional
Software	microsoft office, evernote, kindle and more
Numeric Keypad	no
Touch Screen	no
Screen Type	other
Screen Size	15.6 inches
Screen Resolution	1366 x 768 (hd)
Processor Brand	amd
Processor Model	amd a8-series
Type of Memory	ddr3
System Memory	4 gigabytes
System Memory Expansion	4 gigabytes
Audio Type	dolby enhanced audio v2
Speakers Type	stereo
Backlit Keyboard	no
Card Reader	yes
Touchpad	none
Battery Type	lithium-ion

Weight and Dimensions

Depth	9.64 inches
Height	1.12 inches
Width	14.84 inches
