Lenovo ThinkPad Edge E545 - 1200 Optical Drive Sub Card

1200Opticaldrivesubcard
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage62
•“1040Opticaldriveorblankbezel”onpage64
•“1110Keyboard”onpage73
•“1120Keyboardbezel”onpage76
Removalstepsoftheopticaldrivesubcard
1
2
Wheninstalling:Makesurethattheconnectorisattachedrmlytothesystemboard.
