Lenovo ThinkPad Edge E545 Service Manual

1160Powerbuttonsubcard
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage62
•“1040Opticaldriveorblankbezel”onpage64
•“1110Keyboard”onpage73
•“1120Keyboardbezel”onpage76
Removalstepsofthepowerbuttonsubcard
1
2
2
StepScrew(quantity)Color
Torque
1
M2×3mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
1170Cardreadersubcard
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage62
•“1040Opticaldriveorblankbezel”onpage64
•“1110Keyboard”onpage73
•“1120Keyboardbezel”onpage76
84HardwareMaintenanceManual
