3
4
5
Wheninstalling:MakesurethattheLCDconnectorisattachedrmly.
Removalstepsofthehinges
1
1
1
1
1
1
2
2
StepScrew(quantity)Color
Torque
1
M2×3mm,wafer-head,nylon-coated,smallhead(6)
Black0.181Nm
(1.85kgf-cm)
2030CameraandLCDcableswithdualmicrophones
Foraccess,removetheseFRUsinorder:
“1010Batterypack”onpage62
“1020Largebottomcover”onpage62
“1030Smallbottomcover”onpage63
“1040Opticaldriveorblankbezel”onpage64
“1070PCIExpressMiniCardforwirelessLANandbracket”onpage68
“1110Keyboard”onpage73
“1120Keyboardbezel”onpage76
“1190RJ45subcard”onpage87
“1210LCDunit”onpage90
Chapter9.RemovingorreplacingaFRU99
