•“2010LCDbezelassembly”onpage96
•“2020LCDpanelandhinges”onpage97
Removalstepsofthecamera
Note:Thecameraisonlyavailableinsomemodels.
2
1
StepScrew(quantity)Color
Torque
2
M2×3mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
Wheninstalling:Makesurethattheconnectorisattachedrmly.
3
4
