Lenovo ThinkPad Edge E545 - 1150 Speaker Assembly

7
7
7
StepScrew(quantity)Color
Torque
7
M2×5mm,wafer-head,nylon-coated(3)Silver
0.181Nm
(1.85kgf-cm)
8
9
Wheninstalling:Makesurethattheconnectorisattachedrmlytothesystemboard.
1150Speakerassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage62
•“1040Opticaldriveorblankbezel”onpage64
•“1110Keyboard”onpage73
•“1120Keyboardbezel”onpage76
Removalstepsofthespeakerassembly
Forsomemodels:
82HardwareMaintenanceManual
