Lenovo ThinkPad Edge E545 - 1100 Thermal Pipes

•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage62
Removalstepsofthethermalfan
Note:Yourmodelmightlookslightlydifferentfromthefollowingillustrations.
Loosenthescrews2.
1
2
2
2
Wheninstalling:Makesurethattheconnectorisattachedrmlytothesystemboard.
3
Wheninstalling:Donotpressthetopofthefancoverandthefanhub.
1100Thermalpipes
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage62
•“1090Thermalfan”onpage70
Removalstepsofthethermalpipes
Note:Yourmodelmightlookslightlydifferentfromthefollowingillustrations.
Chapter9.RemovingorreplacingaFRU71
