RemovalstepsofthewirelessantennaassemblyandLCDrearcoverassembly
ReleasetheantennacablesfromthecableguidesontheLCDrearcoverassembly.
1
1
1
2
2
2
2
1
3
3
Cablerouting:Whenyouinstallthewirelessantennaassembly,routethecablesasshowninthefollowing
illustration.
Attention:Whenyouroutethecables,makesurethattheyarenotsubjecttoanytension.Tensioncould
causethecablestobedamagedbythecableguides,orawiretobebroken.
