Removalstepsofthekeyboardbezel
Note:Yourmodelmightlookslightlydifferentfromthefollowingillustrations.
1
1
1
1
1
1
1
1
1
1
1
2
2
2
StepScrew(quantity)Color
Torque
1
M2×8mm,wafer-head,nylon-coated(11)
Black0.181Nm
(1.85kgf-cm)
2
M2×3mm,wafer-head,nylon-coated(3)
Black0.181Nm
(1.85kgf-cm)
3
3
3
StepScrew(quantity)Color
Torque
3
M2×5mm,wafer-head,nylon-coated(3)Silver
0.181Nm
(1.85kgf-cm)
Chapter9.RemovingorreplacingaFRU77
