Lenovo ThinkPad Edge E545 Service Manual

•“1020Largebottomcover”onpage62
•“1030Smallbottomcover”onpage63
•“1040Opticaldriveorblankbezel”onpage64
•“1050Memorymodules”onpage65
•“1060Harddiskdriveassembly”onpage66
•“1070PCIExpressMiniCardforwirelessLANandbracket”onpage68
•“1080Backupbattery”onpage70
•“1090Thermalfan”onpage70
•“1100Thermalpipes”onpage71
•“1110Keyboard”onpage73
•“1120Keyboardbezel”onpage76
•“1130Microprocessor”onpage78
Removalstepsofthesystemboard
Attention:Thefollowingcomponentssolderedonthetopsideofthesystemboardareextremelysensitive.
Whenyouservicethesystemboard,avoidanykindofroughhandling.
aMicroprocessor
bPlatformControllerHub(PCH)
cGraphicsProcessingUnit(GPU)
Formodelswithadiscretethermalmodule
a
c
b
80HardwareMaintenanceManual

Lenovo ThinkPad Edge E545 Specifications

General

OS	windows 7 professional
Software	microsoft office, evernote, kindle and more
Numeric Keypad	no
Touch Screen	no
Screen Type	other
Screen Size	15.6 inches
Screen Resolution	1366 x 768 (hd)
Processor Brand	amd
Processor Model	amd a8-series
Type of Memory	ddr3
System Memory	4 gigabytes
System Memory Expansion	4 gigabytes
Audio Type	dolby enhanced audio v2
Speakers Type	stereo
Backlit Keyboard	no
Card Reader	yes
Touchpad	none
Battery Type	lithium-ion

Weight and Dimensions

Depth	9.64 inches
Height	1.12 inches
Width	14.84 inches
