5.Routethecablesthroughthedrivebayholeinthefrontandthenslidetheopticaldriveintothedrive
bayuntilitsnapsintoposition.
Figure15.Installingtheopticaldrive
6.Connectthepowercabletotheopticaldrivepowerconnectoronthebackplane.See“Locating
connectorsonthebackplane”onpage18.
7.ConnectthesignalcabletotheSATA5connectoronthesystemboard.See“Locatingpartsonthe
systemboard”onpage15.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage67
.
Removingahot-swapharddiskdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage19.
Thissectionprovidesinstructionsonhowtoremoveahot-swapharddiskdrive.Thissectionappliesonlyto
servermodelsthathavehot-swapharddiskdrivesinstalled.
Attention:Tomaintainpropersystemcooling,donotoperatetheserverformorethan10minuteswithout
eitheradriveorallerpanelinstalledineachdrivebay.
Toremoveahot-swapharddiskdrive,dothefollowing:
Note:Youdonothavetoturnofftheserverwhenremovingahot-swapharddiskdrive.
30ThinkServerUserGuide
