a.Notethebottomviewofthebatterycardassembly.

Figure38.Bottomviewofthebatterycardassembly

1J1board-to-boardconnector

2J2remoteconnector(reservedforuse)

b.Withthefrontsideup,placetheRAIDcontrolleronaat,clean,static-freesurface.

c.HoldthebatterycardassemblywiththebatterysideupandtheJ1board-to-boardconnector

liningupwiththeJ6B1BBUconnector

1ontheRAIDcontroller.Carefullypressthebatterycard

assemblyontotheRAIDcontrollersothatthetwoconnectorsarermlyjoined.Then,securethe

batterycardassemblytotheRAIDcontrollerwiththethreescrewsandthestandoffsthatcome

withthebatterycardassemblyaccessorykit.

Figure39.InstallingthebatterycardassemblyontotheRAIDcontroller

1J6B1BBUconnector

Chapter5.Installing,removing,orreplacinghardware53
