6.ConnecttheminiSASsignalcabletoports0-3ontheRAIDcontroller.
Note:Usethe400mm(15.75inches)miniSASsignalcable.
Figure40.ConnectingtheminiSASsignalcabletotheRAIDcontroller
1Ports0-3
2Ports4-7(reservedforuse)
7.InstalltheRAIDcontrollerintoanappropriatePCIcardslotontherisercardassembly.Then,install
thescrewtosecuretheRAIDcontrollerinplace.
Figure41.InstallingtheRAIDcontrollerintothePCIcardslotontherisercardassembly
8.InstalltherisercardassemblywiththeRAIDcontrollerintoanappropriatePCIcardslotonthesystem
board.
54ThinkServerUserGuide
