Frontviewoftheserver
Thefrontviewoftheservervariesbymodel.Theillustrationsinthistopicshowtheserverfrontviews
basedonthesupportedinternaldrives:
•“Frontviewofservermodelswith3.5-inchdrives”onpage17
•“Frontviewofservermodelswith2.5-inchdrives”onpage18
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Frontviewofservermodelswith3.5-inchdrives
Figure3.Frontviewofservermodelswith3.5-inchdrives
1Frontpanel
2Slimopticaldrive(availableonsomemodels)
3Pull-outinformationcard
4Rackhandle(right)
53.5-inch-drivebays(0-3)6Rackhandle(left)
1Frontpanel
Fordetailedinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Front
panel”onpage19.
2Slimopticaldrive
SomeservermodelscomewithaslimSATAopticaldrive.
3Pull-outinformationcard
Themachinetype,model,andserialnumberlabeloftheserverisattachedonthepull-outinformationcard.
See“Machinetype,model,andserialnumberlabel”onpage15.
4Rackhandle(right)
6Rackhandle(left)
Ifyourserverisinstalledinarackcabinet,youcanusetherackhandlestohelpyouslidetheserveroutof
therackcabinet.Youalsocanusetherackhandlesandscrewstosecuretheserverintherackcabinetso
thattheservercannotslideout,especiallyinvibration-proneareas.Formoreinformation,refertotheRack
InstallationInstructionsthatcomeswithyourserver.
53.5-inch-drivebays(0-3)
TheEMIintegrityandcoolingoftheserverareprotectedbyhavingalldrivebayscoveredoroccupied.
Thenumberoftheinstalledharddiskdrivesinyourservervariesbymodel.Thevacanthard-disk-drive
baysareoccupiedbydummyhard-disk-drivetrays.
Whenyouinstalldrives,followtheorderofthedrivebaynumbers.
Chapter3.Productoverview17
