Frontviewofservermodelswith2.5-inchdrives
Figure4.Frontviewofservermodelswith2.5-inchdrives
1Frontpanel
2Pull-outinformationcard
3Rackhandle(right)42.5-inch-drivebays(0-7)
5Slimopticaldrive(availableonsomemodels)6Rackhandle(left)
1Frontpanel
Fordetailedinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Front
panel”onpage19.
2Pull-outinformationcard
Themachinetype,model,andserialnumberlabeloftheserverisattachedonthepull-outinformationcard.
See“Machinetype,model,andserialnumberlabel”onpage15.
3Rackhandle(right)
6Rackhandle(left)
Ifyourserverisinstalledinarackcabinet,youcanusetherackhandlestoslidetheserveroutoftherack
cabinet;orusetherackhandlesandscrewstosecuretheserverintherackcabinetsothattheserver
cannotslideout,especiallyinvibration-proneareas.Formoreinformation,refertotheRackInstallation
Instructionsthatcomeswithyourserver.
42.5-inch-drivebays(0-7)
TheEMIintegrityandcoolingoftheserverareprotectedbyhavingalldrivebayscoveredoroccupied.
Thenumberoftheinstalleddrivesinyourservervariesbymodel.Thevacantdrivebaysareoccupied
bydummytrays.
Whenyouinstalldrives,followtheorderofthedrivebaynumbers.
5Slimopticaldrive
SomeservermodelscomewithaslimSATAopticaldrive.
18ThinkServerRD350UserGuideandHardwareMaintenanceManual
