Frontpanel
Thefollowingillustrationshowsthecontrols,connectors,andLEDsonthefrontpaneloftheserver.The
frontpanelvariesbymodel.
Figure5.Frontpanel
1NetworkstatusLED
2SystemhealthLED
3PowerbuttonwithpowerstatusLED
4SystemIDbuttonwithIDLED
5DisplayPortconnector
6USB2.0connectors(2)
1NetworkstatusLED
ThenetworkstatusLEDonthefrontpanelhelpsyouidentifythenetworkconnectivityandactivity.
NetworkstatusLED
Color
Description
OnGreen
TheserverisconnectedtoaLAN.
Off
None
TheserverisdisconnectedfromaLAN.
Blinking
Green
TheLANisconnectedandactive.
Chapter3.Productoverview19
