•LenovoThinkServerRAID710PCIeAdapter(hereinafterreferredtoasThinkServerRAID710Adapter)
ThinkServerRAID500Adapter
ThefollowingillustrationshowstheconnectorsontheThinkServerRAID500Adapter.
Figure9.ThinkServerRAID500Adapter
1Port0
Usedtoconnectamini-SASsignalcabletothemini-SASports0-3onthebackplane.
2Port1
Usedtoconnectamini-SASsignalcabletothemini-SASprots4-7onthebackplanefor2.5-inchdrives.
3TR500keyconnector
UsedtoconnectaLenovoThinkServerRAID500RAID5UpgradeKeyforAdvancedRAID.See“Installingor
removingtheLenovoThinkServerRAID500upgradekey”onpage73.
Chapter3.Productoverview27
