InstallingtheRAID110ikey
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage53.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:UseanydocumentationthatcomeswiththeRAID110ikeyandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
ToinstalltheRAID110ikey,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage55.
3.Removetheservercover.See“Removingtheservercover”onpage55.
4.Touchthestatic-protectivepackagethatcontainstheRAID110ikeytoanyunpaintedsurfaceonthe
outsideoftheserver.Then,taketheRAID110ikeyoutofthepackage.
Note:CarefullyhandletheRAID110ikeybyitsedges.
5.LocatetheRAIDupgradekeyconnectoronthesystemboardandtheninserttheRAID110ikeyintothe
RAIDupgradekeyconnectoronthesystemboard.
Figure32.InstallingtheRAID110ikey
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage131.
