•UseanydocumentationthatcomeswiththeThinkServerRAIDSuperCapacitorModuleandfollowthose
instructionsinadditiontotheinstructionsinthistopic.
ToinstalltheThinkServerRAIDSuperCapacitorModule,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage55.
3.Removetheservercover.See“Removingtheservercover”onpage55.
4.Touchthestatic-protectivepackagethatcontainstheThinkServerRAIDSuperCapacitorModuleto
anyunpaintedsurfaceontheoutsideoftheserver.Then,taketheThinkServerRAIDSuperCapacitor
Moduleoutofthepackage.
5.LocatetheplaceforinstallingtheSuperCapacitorModuleintheserver.See“Servercomponents”
onpage23.
6.InstalltheSuperCapacitorModuleintotheholder.
Figure38.InstallingtheSuperCapacitorModuleintotheholder
7.NotetheorientationoftheThinkServerRAIDSuperCapacitorModule.Then,lowertheSuperCapacitor
Moduleandgentlyslideituntilitissecuredbythemountingstudsonthechassis.
Note:Dependingonyourservermodel,refertooneofthefollowingillustrationsbelow.
Figure39.InstallingtheThinkServerRAIDSuperCapacitorModule
8.ConnecttheThinkServerRAIDSuperCapacitorModuletoaRAIDcard.
Whattodonext:
Chapter6.Replacinghardware79
