•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage131.
RemovingtheThinkServerRAIDSuperCapacitorModule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage53.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:UseanydocumentationthatcomeswiththeThinkServerRAIDSuperCapacitorModuleandfollow
thoseinstructionsinadditiontotheinstructionsinthistopic.
ToremovetheThinkServerRAIDSuperCapacitorModule,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage55.
3.Removetheservercover.See“Removingtheservercover”onpage55.
4.DisconnectthecableoftheThinkServerRAIDSuperCapacitorModulefromtheRAIDcard.
5.Gentlylifttheplastictab1thatsecurestheThinkServerRAIDSuperCapacitorModule.Then,slidethe
ThinkServerRAIDSuperCapacitorModuleasshowntocompletelyremoveitfromthechassis.
Figure40.RemovingtheThinkServerRAIDSuperCapacitorModule
