6.RemovetheSuperCapacitorModulefromtheholder.
Figure41.RemovingtheSuperCapacitorModulefromtheholder
7.IfyouareinstructedtoreturntheoldThinkServerRAIDSuperCapacitorModule,followallpackaging
instructionsanduseanypackagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage131.
InstallingorremovingaPCIecard
ThistopicprovidesinstructionsonhowtoinstallorremoveaPCIecard,suchasanEthernetcard,aRAID
card,oranyothersupportedPCIecards.
Note:ThePCIecardisextremelysensitivetoESD.Ensurethatyoureadandunderstand“Handling
static-sensitivedevices”onpage54firstandcarefullyperformtheoperation.
InstallingaPCIecard
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage53.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
ToinstallaPCIecardontherisercardassembly,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage55.
3.Removetheservercover.See“Removingtheservercover”onpage55.
4.RemovetherisercardassemblyonwhichyouwanttoinstallthePCIecard.See“Replacingtheriser
cardassembly”onpage122.
Chapter6.Replacinghardware81
