5.Pivotthecardlatchtotheopenposition.
Figure42.OpeningthePCIecardlatch
6.RemovethePCIeslotbracketfromtherisercardassembly.Storethebracketincasethatyoulater
removethePCIecardandneedthebrackettocovertheplace.
Figure43.RemovingaPCIeslotbracket
7.Touchthestatic-protectivepackagethatcontainsthePCIecardtoanyunpaintedsurfaceontheoutside
oftheserver.Then,takethePCIecardoutofthepackage.
Note:CarefullyhandlethePCIecardbyitsedges.
82ThinkServerRD350UserGuideandHardwareMaintenanceManual
