24.Reinstallallpartsthatyouhaveremovedonebyoneinthereversedsequenceasyouremovethem.
Connectallcablestothenewsystemboard.Refertotheinformationthatyouhavenoteddownandthe
relatedtopicsin“Installing,removing,orreplacinghardware”onpage67
.
25.Ifyouareinstructedtoreturntheoldsystemboard,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Theoldsystemboardmustbereturnedwithtwomicroprocessorsocketcoverstoprotectthepinsonthe
microprocessorsocketsduringshippingandhandling.Usethemicroprocessorsocketcoversremoved
fromthenewsystemboard.
Toinstallamicroprocessorsocketcoverontheoldsystemboard,dothefollowing:
1.Closethemicroprocessorretainer.Closethesmallhandle1firstandthenclosethesmallhandle
2.Ensurethattheretainerislockedintopositionandthenewmicroprocessorissecurelyseatedin
thesocket.
Note:Therearetwomarksonthemicroprocessorretainer.Ensurethatyouclosethesmallhandle
markedwith
firstandthenclosethesmallhandlemarkedwith.Alwaysfollowthecorrectsequence
whenyouclosethesmallhandles.
Figure166.Securingthemicroprocessorretainer
2.Positionthemicroprocessorsocketcoverabovethemicroprocessorsocketsothatthesmalltriangle1
onthesocketcoverfacesthesmalltriangle2onthemicroprocessorretainer.Then,carefullypressthe
socketcoverstraightdownintothesocketuntilitsnapsintoposition.
Figure167.Installingthemicroprocessorsocketcover
Chapter6.Replacinghardware177
