ThinkServerRAID520iPCIeAdapter
TheRAID520iAdapterprovidesadvancedSATA/SAShardwareRAIDfunctions.Thefollowingillustration
showstheconnectorsontheadapter.
Figure16.ThinkServerRAID520iPCIeAdapter
1Connector0
Usedtoconnectthemini-SASsignalcableconnectoronthebackplanetosupportHDD0-3.
2Connector1
Usedtoconnectthemini-SASsignalcableconnectoronthebackplanetosupportHDD4-7.
3J3connector
UsedtoconnecttoaThinkServerRAID520iupgradekey.
34ThinkServerRD450UserGuideandHardwareMaintenanceManual
