LenovoThinkServerRAID710PCIeAdapter
TheLenovoThinkServerRAID710PCIeAdapterisusedtoprovideadvancedSATA/SAShardwareRAID
functions.ThefollowingillustrationshowstheconnectorsontheRAIDcard.
Figure17.LenovoThinkServerRAID710PCIeAdapter
1Connector1
UsedtoconnecttotheSASconnector1(ports0–3)onthebackplaneforuptoeight3.5-inchdrives.See
“Backplaneforuptoeight3.5-inchdrives”onpage37
.
2Connector2
UsedtoconnecttotheSASconnector2(ports4–7)onthebackplaneforuptoeight3.5-inchdrives.See
“Backplaneforuptoeight3.5-inchdrives”onpage37.
3ThinkServerRAIDSuperCapacitorModuleconnector
UsedtoconnectthecableofaThinkServerRAIDSuperCapacitorModule.
