ThinkServerRAID720iPCIeAdapter
TheRAID720iAdapterprovidesadvancedSATA/SAShardwareRAIDfunctions.Thefollowingillustration
showstheconnectorsontheadapter.
Figure18.ThinkServerRAID720iPCIeAdapter
1Connector0
Usedtoconnectthemini-SASsignalcableconnectoronthebackplanetosupportHDD0-3.
2Connector1
Usedtoconnectthemini-SASsignalcableconnectoronthebackplanetosupportHDD4-7.
3ThunderboltFlashModuleconnector
UsedtoconnectaThunderboltMemorymodule(hereinafterreferredtoasTMM).
Hot-swap-drivebackplane
Yourservercomeswithoneofthefollowingdrivebayandbackplaneconfigurations:
DrivebaysizeDrivebayquantityBackplanequantityDrivetype
3.5-inch81
Hot-swap,SATAorSAS
3.5-inchharddiskdriveor
2.5-inchsolid-statedrive
2.5-inch81
Hot-swap,SATAorSAS
Harddiskdriveorsolid-state
drive
2.5-inch162
Hot-swap,SATAorSAS
Harddiskdriveorsolid-state
drive
2.5-inch242
Hot-swap,SATAorSAS
Harddiskdriveorsolid-state
drive
