LenovoThinkServerRAID500PCIeAdapter
TheLenovoThinkServerRAID500PCIeAdapterisusedtoprovideadvancedSATA/SAShardwareRAID
functions.ThefollowingillustrationshowstheconnectorsontheRAIDcard.
Figure15.LenovoThinkServerRAID500PCIeAdapter
1Connector0
UsedtoconnecttotheSASconnector1(ports0–3)onthebackplaneforuptoeight3.5-inchdrives.See
“Backplaneforuptoeight3.5-inchdrives”onpage37.
2Connector1
UsedtoconnecttotheSASconnector2(ports4–7)onthebackplaneforuptoeight3.5-inchdrives.See
“Backplaneforuptoeight3.5-inchdrives”onpage37.
3RAID500upgradekeyconnector
UsedtoconnectaLenovoThinkServerRAID500upgradekeyforadvancedRAID.
