Lenovo ThinkSystem ST250 V2 - Install a RAID Flash Power Module

Figure 111. Removing the RAID flash power module and bracket assembly from the chassis
Step 4. Remove the RAID flash power module from the bracket.
a.
Gently pull the tab on the bracket.
b.
Remove the module from the bracket.
Figure 112. Removing the RAID flash power module from the bracket
After this task is completed
If you are instructed to return the component or optional device, follow all packaging instructions, and use
any packaging materials for shipping that are supplied to you.
Install a RAID flash power module
Follow instructions in this section to install a RAID flash power module (supercap).
About this task
To avoid potential danger, read and follow the following safety statements.
• S002
Chapter 4. Hardware replacement procedures 189
