Internal storage drives
Internal storage drives are devices that your computer uses to read and store data. You can add drives to
your computer to increase storage capacity and enable your computer to read other types of media. Internal
storage drives are installed in bays.
When you remove or install an internal storage drive, note the type and size of the drive that each bay
supports and correctly connect the required cables. Refer to the appropriate section in Chapter 9 “Hardware
removal and installation” on page 97 for instructions on how to remove or install internal storage drives for
your computer.
The following illustration shows the locations of the storage drives.
Note: The computer hardware might look slightly different from the illustration.
Figure 7. Storage-drive bay locations
1 Type-1 storage-drive cage
2 SD card slot (available on some models)
3 Flex bay (available on some models)
4 M.2 solid-state drive slot
40 P330 Hardware Maintenance Manual
