6.2 Configuring the Controller (EtherCAT master)
The Controller (EtherCAT master) must be configured before communication with the
communication module is possible.
In order to configure EtherCAT networks, you always need a configuration software for the
Controller, e.g.:
• Lenze »PLC Designer«
• Beckhoff »TwinCAT«
These are software systems for the programming of control programs, EtherCAT configuration, real-
time execution, and diagnostics.
The parameters of the communication module are stored in the internal configuration memory and
can be used by the master for the device identification.
For device detection (fieldbus scan), the corresponding device descriptions of the Lenze device
family are used.
6.2.1 Installing device description files
The current XML device description files required for configuring the EtherCAT device can be found
in the download area at:
www.lenze.com
The following device description file can be installed via the EtherCAT configuration software.
 "Controller-based Automation EtherCAT" communication manual
Here you'll find some detailed information relating to the EtherCAT configuration with
the Lenze »PLC Designer«.
Device description file Used for ...
Lenze_E94AYCET_V100_yymmdd.xml SW version 01.01 of the E94AYCET communication
module
Lenze_E94AYCET_IO_yyyymmdd.xml From SW version 02.00 of the E94AYCET communication
module in connection with Servo Drives 9400
Lenze_E94AYCET_MOTION_yyyymmdd.xml From SW version 02.00 of the E94AYCET communication
module in connection with the technology application
"CiA402" and Servo Drives 9400
Wildcards in the file name
yyyy Year
mm Month
dd Day
