Lenze EPM-H520 - Installation; Mechanical Installation

Installation
L
64
EDBEPM-H520 DE/EN/FR 4.0
3 Installation
3.1 Mechanical installation
The dimensions for the mounting cut-out can be found in the Technical Data. (% 63)
1. Insert the keypad
& into the cut-out.
0
h520_003
2. Use U washers ' (8 pcs).
3. Bolt the nuts
( on the threaded
studs
) and tighten them.
2
1
3
h520_015
