Lenze EPM-H520 - Project Transfer to the Keypad

Commissioning
L
74
EDBEPM-H520 DE/EN/FR 4.0
4.2 Project transfer to the keypad
4.2.1 Connecting keypad and PC
$
$$
$ Stop!
Only connect PC and keypad when the units are switched off!
l
HMI Designer
01
1
2
3
4
5
+24 VDC
N.C.
0 VDC
CAN+
N.C.
Shield
CAN-
V-
1
2
3
4
INPUT VOLTAGE:
18 - 32 VDC 15 W
fuse 1.25 A
MSP
LPT
back-up expansion
h520_005
Fig. 4-1 Connecting keypad and PC
! EPZ-H110 download cable & on the MSP interface at the keypad and COM1 or COMx on the PC
)
