Operation
1
4
7
2
5
8
0
3
6
9
L
89
EDBEPM-H520 DE/EN/FR 4.0
5.5 Calling up help messages
!
Help messages
– can be assigned to pages, warnings and information messages,
– contain useful notes to make handling easier,
– must have been programmed with the planning tool “HMI Designer”,
– for alarm and information messages can have a max. size of 16 lines of max. 74 characters
(normal character size),
– for project pages can have a max. size of 16 lines of max. 80 characters (normal character
size).
If you want to ... Press keys ... Example
A) call up the help for an information or
warning message.
1. Touch the message field if ”HELP” is
indicated together with the information
or warning message.
ESC
Pressure exceeds
safety limit
125.5
13-09-2000 10:45a
Temperature exceeds
safety limit
1700
13-09-2000 10:55a HELP
Water level below
working threshold
-10
13-09-2000 11:00a HELP
Gas saturation in the stokehole
has reached limit value
345
13-09-2000 09:00a
2. Close help.
ESC
ESC
Pressure exceeds
safety limit
125.5
13-09-2000 10:45a
Temperature exceeds
safety limit
1700
13-09-2000 10:55a HELP
Water level below
working threshold
-10
13-09-2000 11:00a HELP
Gas saturation in the stokehole
has reached limit value
345
13-09-2000 09:00a
ESC
Pressure exceeds
safety limit
125.5
13-09-2000 10:45a
Temperature exceeds
safety limit
1700
13-09-2000 10:55a HELP
Water level below
working threshold
-10
13-09-2000 11:00a HELP
Gas saturation in the stokehole
has reached limit value
345
13-09-2000 09:00a
B) call up help for a page
1. Touch the corresponding field if help is
available.
2. Close help.
ESC
